Back to Floorplans
New
Trail Runner
270BH
BASE MSRP*
$41,927
*Manufacturer's Suggested Retail Price (also referred to as "MSRP", "Base Price" or the "Starting At" price) excludes destination/delivery charges, taxes, title, license and registration fees, dealer fees and total of options fees. Check with your local dealer for pricing.
Specifications
TITLE
270BH
GVWR
7,748 lbs
DRY WEIGHT
6,086 lbs
HITCH WEIGHT
748 lbs
CARGO CAPACITY
1,630 lbs
WIDTH
8'-1/2"
HEIGHT
11'-2"
LENGTH
31'-11-1/2
SQFT
267'
SLEEP CAPACITY
9+
AXLES
2 x 3,500 lbs
FRESH TANK
41 gal
GREY TANK
80 gal
BLACK TANK
40 gal
WATER HEATER
0 gal
FURNACE
30,000 BTU
AIR CONDITIONER
13,500 BTU
LP TANK CAPACITY
2 x 20 LBS
REFRIGERATOR
10 Cu Ft/12V/Res.
CONVERTOR
55 AMP
SHORE POWER
30 AMP
NUMBER OF SLIDES
1
MAIN SLIDE HEIGHT
5'-9-1/4"
BEDROOM HEIGHT
6'-8"
AWNING LENGTH
18'
COOK TOP
3 Burner
TRADITIONAL OVEN
Yes
CONVECTION OVEN
No
BED SIZE
Queen
Features
- Secure step entry steps with extra-large handle
- Griddle in all outside kitchens - More versatile than two burner stove
- Hybrid Aluminum Front Profile - Aerodynamic radius front cage structure for better wind and water deflection, adding strength and reduces tongue weight
- Mammoth Storage - Industry leading 57 cu. Ft. Pass Thru Finished Storage
- Slide Topper Prep and Tire Pressure Monitoring System Prep Allowing for Easy Customer Upgrades
- Diamond plate stone guard, Radial tires with steel wheels, and molded fender skirts
- Bumper with drain hose carrier, end caps
- Radius-cornered baggage doors
- Upgraded axles with electric brakes
- Radius-cornered fiberglass entrance door with screen door
- Molded rain guttering with extra-long drip spouts
- Blue LED lit outside speakers and accent lighting under the coach
- Power awning with LED lights
- Backup camera prep
- LP quick connect
- Exterior shower
- Power stabilizer jacks
- Black tank flush
- Master Suite - Residential 60"x 80" queen bed , oversized wardrobes, built in CPAP storage, and wireless cell charging stations
- Upgraded pressed counters in all kitchens
- Modern Farmhouse interior details with woodgrain floor and matching facia.
- Large dark drawer pulls and glass cabinet inserts
- Woven flooring and flush floors in slide outs
- LED lighting throughout the coach
- Roller shades in main living area
- Hybrid aluminum front profile- Aerodynamic radius front cage structure for better wind and water deflection, adding strength and reduces tongue weight
- 5/8” Main floor decking
- Roof rafters wood tapered 4-1/2” trusses
- Wall studs on 16” centers
- Electric rack and pinion slide-outs with manual override
- Fully walkable roof
- 8’ Exterior width
- 80” Interior ceiling height
- 2” x 3” Longitudinal floor joists
- Cambered structural steel I-beam frame
- Heated enclosed underbelly
- Hook-up for city water
- Systems monitor panel
- 12V Demand water pump
- 13.5K BTU dual ducted central A/C
- 12V Electrical system with deluxe 110V 45-Amp power converter
- Gas/electric DSI hot water heater
- 30-Amp power cord
- 110V GFCI protected exterior receptacle
- Auto-ignition furnace with wall thermostat
- In-floor ducted heat with 30K BTU furnace
- Water system winterization kit
- Water heater bypass
- Heated and enclosed fresh water tank
- 20# LP bottles with cover
- Radial tires with steel wheels
- Upgraded axles with EZ lube hubs and electric brakes
- Spare tire carrier
- Tall backsplash
- Stainless steel appliances
- 10 cu ft. 12volt refrigerators
- Microwave oven
- Stainless steel residential-style sink
- Flush mount 3-Burner cook top and range hood with light and exhaust fan
- Ball bearing drawer guides and finished drawer boxes
- Large oven
- 60”X80” Queen bed with bedspread
- Oversized wardrobes
- Built in CPAP storage
- Wireless cell charging stations
- TV hookups
- Wardrobe and Under-bed storage
- Overhead cabinets above bed
- Designer shower curtain
- ABS tub/shower surround
- Bathroom power vent
- Toilet with foot flush
- Glass door for neo-angle showers
- Skylight in bathroom
- Towel ring
- Propane alarm
- Break-away switch
- Dead-bolt lock on entrance door
- Dual hitch safety chains
- Smoke alarm
- Multiple egress windows
- Fire extinguisher
- Carbon monoxide alarm
Options
- Spare tire carrier
- Bunk room dinette (30USBH only)
- LED HDTV
- Power tongue jack
- 15,000 BTU A/C in place of 13,500 A/C
- Dual sleeper hide-a-bed (select models)
- 50 Amp service with second A/C (select models)
Interior Décor - Magnolia
The Look
**Manufacturer's Suggested Retail Price (also referred to as "MSRP", "Base Price" or the "Starting At" price) excludes destination/delivery charges, taxes, title, license and registration fees, dealer fees and total of options fees. Check with your local dealer for pricing.
