North Trail Ultra-Lite Travel Trailer - East & West Coast Production Model
24BHS
MSRP
$42,851**
Specifications
TITLE
24BHS
GVWR
7,570 lbs
DRY WEIGHT
5,500 lbs
HITCH WEIGHT
570 lbs
CARGO CAPACITY
2,038 lbs
WIDTH
8'-1/2"
HEIGHT
11'-4"
LENGTH
27'-10"
SQFT
278'
SLEEP CAPACITY
7-8
AXLES
2 x 3,500 lbs
FRESH TANK
45 gal
GREY TANK
40 gal
BLACK TANK
40 gal
WATER HEATER
6 gal
FURNACE
30,000 BTU
AIR CONDITIONER
13,500 BTU
LP TANK CAPACITY
2 x 20 LBS
REFRIGERATOR
10/12v/RES
CONVERTOR
55 AMP
SHORE POWER
30 AMP
NUMBER OF SLIDES
1
MAIN SLIDE HEIGHT
5'-7-1/4"
BEDROOM HEIGHT
6'-8"
AWNING LENGTH
19'
COOK TOP
3 Burner
TRADITIONAL OVEN
Yes
CONVECTION OVEN
No
BED SIZE
King
Highlights
Outdoor Kitchen
Comfort Select Gel Infused
USB port accessibility
Dream Kitchen
Smart Design Bathroom
Features
- Prepped for anything – Prepped for tire pressure monitoring system, slide out topper, back up camera, solar prep with the option to upgrade, WiFi prepped, and rear ladder
- Super King Kong sized pass-through storage
- 4˝ thick vacuum bond laminated roof*
- 2” Thick Azdel fortified sidewall construction
- Secure ride equipped – featuring top of line axles, galvanized metal wheel wells, Wide Trax suspension, heated and enclosed underbelly
- Friction hinge on every door
- Slam latch baggage doors
- E-Z Lube hubs
- Power awning w/ LED lights
- Outside speakers
- Outside shower
- Exterior 120 Volt outlet
- Large assist entry handle
- Aluminum flip up entry step
- Black tank flush
- Battery disconnect
- Diamond plate front rock guard
- BTU furnace – 30k BTU
- Gas/electric DSI water heater
- Fresh water 51 Gallons (includes water heater)
- Gray/Black 40 Gallons
- Electric slide outs
- Solar Prep
- Black tank flush system
- *Some models produced in our Idaho facility may vary from specs identified
- Blackout roller shades in main slideout and bedroom (where applicable)
- Butcher block style kitchen countertops
- Stainless steel appliances
- Value hide – E – center with hidden valuable storage area (most models)
- Comfort select 72” x 80” gel infused residential king bed mattress
- Monitor panel in bathroom
- Dual ducted AC
- Gas/Electric DSI quick recovery water heater
- WiFi prep
- Upgraded & overstuffed residential furniture
- Cable TV prep
- Bluetooth Capable FM Radio with HDMI pass through
- TV antenna with booster
- Designer accent walls
- LED lights
- Residential interior doors
- *Some models produced in our Idaho facility may vary from specs identified
- 2” thick Azdel laminated sidewalls with lightweight non wood substrate and sound barrier.
- Heated and enclosed underbelly
- 8 ft. wide design
- Power Tongue and Stabilizer Jacks
- Fully walkable roof
- Diamond plate front rock guard
- Rock block galvanized wheel wells
- 8” wide durable tongue and groove plywood floors
- Tinted safety glass windows
- Finished and insulated super king kong sized pass through storage (67.5 CU ft of storage)
- Nitro filled 14” radial tires on lightweight trailers
- Nitro filled 15” radial tires on king slide outs (except 25LRSS)
- Aluminum wheels
- Spare tire
- Wide Traxx Suspension
- E-Z lube hubs
- Steel ball-bearing, full extension drawer guides
- Stainless Steel Sink
- Infinity edge counter tops
- Hidden Hinges on Cabinetry
- High Rise Kitchen Faucet
- Conventional oven
- Three-burner range with glass top
- Premium flooring – tear, slip, mold, mildew and cold crack resistant
- Power range hood with light
- 10.7 cu. Ft. 12 Volt Refrigerator
- LED reading and ceiling lights
- 110 Volt outlets on both nightstands
- Quick Store underbed storage
- Residential headboard
- Shower skylight
- Tub surround
- Medicine cabinet
- Bathroom power vent
- Smoke detector
- LP detector
- Fire extinguisher
Options
- 15K BTU A/C
- 50 Amp & 2nd A/C (some models)
- Upgraded decorative glass inserts
- Large viewing window in kitchen
- Full extension ball bearing drawer guides
- Deep pantry with removable shelves (most models)
- Highrise faucet
- *Kitchen package is forced on all models
- Laminated crowned roof system (N/A on West Coast models)
- Block foam brick insulation
- Aluminum construction
- Enclosed and heated underbelly
- Tinted safety glass windows
- 2″ thick sidewall construction with Azdel
- Four stabilizer jacks
- WIDE-TRAXX axle placement
- HD leaf spring suspension
- Dual 20 lb. LP tanks
- Weather Guard thermal protection
- *package is forced on all models
- Power stabilizer jacks
- Power Tongue jack
- LED lighting with quick charge USB ports
- *package is forced on all models
- 50″ HDTV
- 26″ Fireplace
- *package is forced on most models 25 and up
Interior Décor Urban Cottage
The Look
Interior Décor Crystal Bay
The Look
**Manufacturer's Suggested Retail Price (also referred to as "MSRP", "Base Price" or the "Starting At" price) excludes destination/delivery charges, taxes, title, license and registration fees, dealer fees and total of options fees. Check with your local dealer for pricing.
