Specifications

TITLE Lafayette
GVWR 18000
DRY WEIGHT 15251
HITCH WEIGHT 3918
CARGO CAPACITY 2,697 lbs
WIDTH 8'-0"
HEIGHT 13'-3"
LENGTH 43'-10"
SQFT 426'
SLEEP CAPACITY 5-6
AXLES 2 x 8000
FRESH TANK 80 gal
GREY TANK 90 gal
BLACK TANK 90 gal
WATER HEATER 12 gal
FURNACE 35,000 BTU
AIR CONDITIONER 15,000 BTU
AIR CONDITIONER2 15,000 BTU
AIR CONDITIONER3 15,000 BTU
LP TANK CAPACITY 2 x 30 LBS
REFRIGERATOR 20.8 Cu Ft/12V/Res.
CONVERTOR 80 AMP
SHORE POWER 50 AMP
NUMBER OF SLIDES 5
MAIN SLIDE HEIGHT 5'-3"
BEDROOM HEIGHT 6'-4"
AWNING LENGTH 16'
COOK TOP 3 Burner
TRADITIONAL OVEN Yes
CONVECTION OVEN Yes
GENERATOR PREP Standard
BED SIZE King

Highlights

Power Tilting King Bed
Spa Bath
Oversized Walk-In Closets
Deep Residential Dressers

Features

  • Three sided accessed basement with 30% more storage, clean paneled compartments and slam latch doors
  • “Hidden” main basement ceiling mounted MORryde tool tray
  • Lightweight, non-wood Azdel laminated sidewalls with laminated slide-out end walls
  • MORryde air compressor mounted door side with off door side quick connect port and 2.5 gallon tank
  • “Glide Ride” 8,000lb Dexter axles on H-range tires w/ 3 3/8’’ brakes, MORryde LRE 4000 and gas shocks
  • MORryde strut assisted entry door with deeper top step at entry
  • Rear and side security camera prep
  • 2˝ Accessory receiver
  • Unobstructed “Super Store More” triple accessed pass-through main basement storage
  • MORryde LRE 4000 suspension with 3’’ of vertical travel
  • 6-point hydraulic landing gear and auto leveling system
  • Full skirt metal covering I-beam chassis near gooseneck
  • Euro style entry door latch with oversized grab handle
  • Full Body Paint (3 color schemes to choose from)
  • MORryde pin box
  • Power cord reel with easy release
  • Dual battery hookup and push button battery disconnect
  • Double power awnings with LED lights
  • Frameless dual pane windows
  • “Secure Stay” ASA multiplex coach controls including HVAC, dimmers and an interior & exterior cameras
  • Angled walk-in closets with deep shelves, double hanging rods, cedar lining and washer/dryer prep
  • “Spa Baths” with solid surface sinks, marble look shower, removable shower head and teak wood seat
  • “Ultra-Upper Deck” bedroom with power tilting king bed, 22’’ deep residential dressers and CPAP nightstands
  • “Tech-centric” dual supercharging USBs, bedroom USBs and 3 wireless charging stations in each unit
  • Whisper Quiet A/C system – includes 3 high output 15,000 BTU A/C units
  • Energy Management System
  • Slow close drawer guides
  • Residential style stereo with DVD Player, radio and Bluetooth capability to phone
  • Sofa with heat, massage, power recline, storage in arms and flip down center work station
  • Cordless vacuum
  • 5100 BTU Fireplace/Heater
  • In-house constructed laminated fiberglass sidewalls
  • Double-welded aircraft quality aluminum superstructure cage construction
  • In-house constructed 3’’ vacuum bonded laminated main and upper deck floors
  • Walkable roof decking with wood roof trusses 16’’ on center or less
  • Radius metal cap at roof/sidewall transition
  • 12˝ I-beam frame with rust prohibitive coating
  • Heated and enclosed underbelly
  • Heated and Insulated holding tanks & gate valves
  • Surge Protection
  • 1000 Watt Invertor
  • 50 Amp Service
  • YETI insulation package (12V heat tape/strips, front cap insulation)
  • 8000# industry leading axles/springs & hubs with aluminum wheels
  • 17.5’’ H-range tires
  • 2-tone “Black and Tan” maple material 100%  hardwood stiles, cabinetry & fascia
  • Amish-crafted natural hardwood cabinet doors with hidden hinges and drawers
  • 30˝ microwave oven over the range
  • In-house milled and finished solid surface countertops throughout
  • Residential size farmhouse stainless steel kitchen sink with butcher block cutting board sink cover
  • Single basin stainless steel kitchen sink with front apron
  • Residential Refrigerator with water and ice
  • Backlit kitchen backsplash panel
  • Adjustable Bedroom Reading Lights
  • Power tilt king bed
  • Two windows in bed slide for cross breeze
  • 6´4˝ bedroom upper deck ceiling height throughout
  • Backlit headboard
  • 32/39’’ LED bedroom television
  • 6´4˝ ceiling height
  • Fan in bathroom
  • Porcelain toilet w/foot flush
  • Glass shower door with towel bar
  • Foldable teak wood seat in shower

Options

  • High-rise coffee table with built in storage
  • Heat pump on main A/C
  • Dishwasher (n/a all floor plans)
  • Stackable washer/dryer
  • Slide out topper awnings
  • 5.5 KW micro quiet Onan generator
  • 300W solar panel with 30 amp controller and 2000W inverter

Interior Décor Sunrise

The Look

Interior Décor Moonbeam

Two-toned Cabinetry

**Manufacturer's Suggested Retail Price (also referred to as "MSRP", "Base Price" or the "Starting At" price) excludes destination/delivery charges, taxes, title, license and registration fees, dealer fees and total of options fees. Check with your local dealer for pricing.
