Specifications
TITLE
37FB
GVWR
15,500 lbs
DRY WEIGHT
12,350 lbs
HITCH WEIGHT
2,760 lbs
CARGO CAPACITY
3,145 lbs
WIDTH
8'-3/4"
HEIGHT
13'-4"
LENGTH
42'-4-1/8"
SQFT
416'
SLEEP CAPACITY
3-4
AXLES
2 x 7,000 lbs
FRESH TANK
65 gal
GREY TANK
90 gal
BLACK TANK
90 gal
WATER HEATER
12 gal
FURNACE
35,000 BTU
AIR CONDITIONER
15,000 BTU
AIR CONDITIONER2
13,500 BTU
LP TANK CAPACITY
2 x 30 LBS
REFRIGERATOR
14.9 Cu Ft/110/LP
CONVERTOR
75 AMP
SHORE POWER
50 AMP
NUMBER OF SLIDES
3
MAIN SLIDE HEIGHT
6'-5-3/4"
BEDROOM HEIGHT
6'-4-1/4"
AWNING LENGTH
20'
COOK TOP
3 Burner
TRADITIONAL OVEN
Yes
CONVECTION OVEN
No
GENERATOR PREP
Optional
BED SIZE
King
Highlights
Oversized Farmhouse Sink
Triple Play Kitchen Countertops
Practical Pantry
Features
- “Store More” triple access door storage in main basement with 30% more storage
- MORryde strut-assisted “Step Above” folding aluminum tread entry staircase
- MORryde CRE3000 rubber suspension system with max vertical travel
- Lightweight Azdel laminated sidewalls with laminated slide-out and rear end walls
- MORryde 12V power cord reel mounted in front basement door space
- Rota flex pin box
- High gloss sidewalls with upgraded vinyl graphics and logo badge on front cap
- 2’’ receiver hitch added to all units
- Large insulated slam latch baggage doors
Universal docking station with all hookups, dump valves, flush, cable/sat, shower and winterization - Hydraulic landing gear with 6 point auto leveling system
- “Triple Play” kitchens with solid surface countertops per floors plans (n/a 33RKS)
- “Barefoot Friendly” carpet free main and upper deck linoleum & marine flooring
- Oversized black stainless single basin farmhouse sink with front apron
- “Practical Pantry” floor to ceiling pantries in every kitchen of every floor plan
- Real wood drawer construction
- In-house milled and finished solid surface countertops throughout
- Night roller shades
- Upgrade 80˝ flip & fold sleeper sofa
- 40’’ wide fireplace with 5000BTU of electric heat
- Two windows in slide for cross breeze
- Washer/dryer prep
- Dual wireless charging stations in kitchen and bedroom
- Seamless corrugated underbelly material
- Heated and enclosed underbelly & gate valves
- In-house constructed laminated fiberglass sidewalls
- Double-welded aircraft quality aluminum superstructure cage construction
- Walkable roof decking with wood roof trusses 16’’ on center or less
- Aluminum framing with dense block foam insulation in sidewalls
- 3/8˝ seamless floor decking
- Battery disconnect
- 10˝ I-beam frame with rust prohibitive coating
- Heavy-duty 12 ply F-rated 16˝ tires with aluminum wheels
- 7,000 lb. Dexter axles with Easy-Lube hubs (all models)
- 2˝ x 12˝ Nev-R-Adjust brakes by Dexter
- Spare tire mounted on easy access bracket
- Oversized single basin stainless steel kitchen sink
- 20˝ deep residential size kitchen drawers
- Real wood drawer construction
- Ball-bearing drawer guides
- In-house milled and finished solid surface countertops throughout
- 3-burner cook top w/oven
- 30˝ microwave oven over the range
- King size bed
- Large, unobstructed under bed storage with gas strut lifting power
- Two windows in slide for better air flow
- 6´4˝ bedroom ceiling height throughout
- Dual switched LED reading lights over bed
- 32’’ LED bedroom television
- 6´4˝ bath ceiling height throughout
- One -piece fiberglass shower with glass door, towel bar and domed skylight
- Porcelain toilet with foot flush
- Air conditioned and heated room
Options
- 12 cubic foot 4 door gas/electric refrigerator
- Generator Prep
Interior Décor Cinderwood
The Look
Interior Décor Beechnut
The Look
